LogicMachine5 Reactor IO v3 is all-in-one controller uniting in one device cross-standard gateway, cloud service integration, complex network logic engine, easy-to create visualization platform, IP Router, I/Os and much more.

Hightlights

• 18 I/O ports
• Built-in KNX TP1, two serial interfaces
• Power-over-Ethernet powering
• Application development and application store
• Cloud ready device with Microsoft Azure, Amazon Web Services and other services supported
• Gateway and uniform way of control of KNX TP1, CAN FT, EnOcean, KNX TP1, ModBus RTU/TCP, BACnet IP, DMX, M-Bus and more
• Unlimited scenario and logic engine
• Amazon Echo, Apple HomeKit, Google Home supported
• Unlimited visualization platform for PC and for touch devices
• Size: 6 DIN units
• Remote KNX bus control and KNX device reprogramming
• Object logging with trends support and data exporting to external servers

LogicMachine5 comparison table 1.2024

I/O specification

• 1 x RS485
• 1 x RS485/RS-232 (switchable in software)
• 1 x USB2.0
• 1 x 10/100 Ethernet with passive PoE support
• 1 x KNX TP1
• 16 x Programmable Analog inputs or Digital outputs (100 mA continues current on output if all 16 ports activated)
• 2 x analog outputs 0-10V
• CAN FT (optional, see Type of Product in the datasheet)
• EnOcean 868MHz (optional, see Type of Product in the datasheet)
• LTE modem (optional, see this product)

Product datasheet and manual

Download LogicMachine5 Reactor IO v3 datasheet here

Download LogicMachine5 manual here


Download LogicMachine5 Reactor IO manual here


Download Mosaic and Cloud manual here

Download DWG file here
